Hubbell 50 Amp 250V Twist-Lock Receptacle, Model CS8369
Pickup available at IES - Mississauga
Usually ready in 4 hours
Shipping & Pickup Information
In-stock items typically ship next business day.
Additional shipping charges may apply to oversized or freight items. Shipping rates calculated at checkout.
Free pickup from our local warehouses in Mississauga & Scarborough. Usually ready within 1 business day.
Returns available on eligible items.
This industrial Twist-Lock® receptacle provides a locking connection for 50 A, 250 V three-phase delta power in indoor industrial installations. Heat-resistant phenolic construction and one-piece brass contacts support heavy-duty use, while screw terminals accommodate solid or stranded copper conductors.
Specifications
| Product type | Industrial Twist-Lock® receptacle |
| Brand | Hubbell Wiring Device-Kellems |
| Current rating | 50 A |
| Voltage and phase | 250 V AC, three-phase delta |
| Configuration | 3-pole, 4-wire grounding; non-NEMA |
| Colour | Black |
| Body, face and insulator | Phenolic |
| Contacts | One-piece brass contacts |
| Termination | Screw terminals with steel terminal screws |
| Conductor accommodation | #10 AWG to #6 AWG, solid or stranded copper wire only |
| Mounting | Screw mounting |
| Environmental conditions | Indoor dry unless protected by additional means |
| Operating temperature | Maximum continuous 75°C; minimum -40°C without impact |
| Current interrupting | Certified for current interrupting at full rated current |
| Dielectric strength | Withstands 2,000 V minimum |
| Flammability | UL 94 V0 |
| Dimensions (L × W × H) | 2.69 × 2.12 × 2.36 in |
| Weight | 0.75 lb |
| UPC | 783585829074 |
