Caseta Pro 1000W Dimmer Switch, White, PD-10NXD-WH-C
Caseta Pro 1000W Dimmer Switch, White, PD-10NXD-WH-C
Pickup available at IES - Mississauga
Usually ready in 4 hours
The Lutron Caséta® Wireless In-Wall Dimmer PRO (PD-10NXD-WH-C) is engineered for professional electricians and contractors who demand reliable, high-capacity dimming on residential and light commercial circuits. Rated at 1000W for incandescent and halogen loads, it handles the full range of lamp types — including CFL and LED — making it the right tool for great rooms, dining areas, feature lighting, and commercial retrofit projects where standard dimmers fall short. The wireless design integrates into the Caséta® ecosystem, supporting Pico remote controls, Caséta motion sensors, and Smart Bridge connectivity for app control, scheduling, and voice assistant compatibility. Built with power failure memory and surge protection to IEC and IEEE standards, this dimmer operates locally without system control — a key advantage on job sites where reliability is non-negotiable. Requires a 1-gang U.S. wallbox; wallplates sold separately.
Specifications
| Brand | Lutron® |
| Series | Caséta® Wireless PRO |
| Part Number | PD-10NXD-WH-C |
| Type | Wireless In-Wall Dimmer Switch |
| Operating Voltage | 120 V~ 50/60 Hz |
| Colour | White |
| Compatible Lamp Types | CFL / Halogen / Incandescent / LED |
| Wireless Communication | Radio Frequency (RF) — compatible with Pico remote controls, Caséta motion sensors, Smart Bridge, and Smart Bridge PRO |
| RF Range (Line-of-Sight) | Up to 60 ft (18 m) to Smart Bridge / Pico / motion sensor |
| RF Range (Through Walls) | Up to 30 ft (9 m) |
| Device Capacity (No Smart Bridge) | Up to 10 Pico remote controls and/or Caséta motion sensors per dimmer |
| Device Capacity (Smart Bridge System) | Up to 75 total wireless devices per system |
| Wallplate Compatibility | Lutron Claro® or designer-style wallplates (sold separately); multi-gang up to 6-gang available |
| Wallbox Requirement | 1-gang U.S. wallbox; 3½ in (89 mm) deep recommended, 2¼ in (57 mm) deep minimum |
| Power Failure Memory | Yes — returns to previously set level upon power restoration |
| Load Status Indicator | Green LEDs |
| Surge Protection | Tested to IEEE C62.41-1991 |
| ESD Protection | Tested to IEC 61000-4-2 |
| Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F), 0%–90% humidity, non-condensing |
| Installation Environment | Indoor use only |
| Regulatory Approvals | cULus Listed, NOM Certified, FCC Approved (Class B, Part 15), Industry Canada Certified, IFTEL Certified |
