Hubbell 30 Amp 250V Industrial Grade Twist-Lock Flush Receptacle, Model HBL8460A
Pickup available at IES - Mississauga
Usually ready in 4 hours
Shipping & Pickup Information
In-stock items typically ship next business day.
Additional shipping charges may apply to oversized or freight items. Shipping rates calculated at checkout.
Free pickup from our local warehouses in Mississauga & Scarborough. Usually ready within 1 business day.
Returns available on eligible items.
This Hubbell industrial-grade straight-blade flush receptacle provides a 30A, 250V AC three-phase connection for industrial equipment installations. Sequenced contacts help provide protection, while one-piece power and ground contacts support the connection. Back and side wired screw terminals accommodate installation in indoor dry locations unless protected by additional means.
Specifications
| Brand | Hubbell Wiring Device-Kellems |
| Device Type | Industrial-grade single straight-blade flush receptacle |
| Amperage | 30 A |
| Voltage | 250 V AC |
| Phase | Three-phase |
| Configuration | 15-30R; 3-pole, 4-wire grounding |
| Wattage | 7,500 W |
| Maximum Horsepower | 3 hp |
| Colour | Black |
| Body Material | Thermoplastic/composite; nylon housing |
| Contact and Terminal Materials | Brass contacts and ground shunt; copper box terminals |
| Mounting | Screw mounting; 0.062 in. pre-plated steel mounting plate |
| Wiring | Back and side wired screw terminals; copper wire only |
| Location Suitability | Indoor dry locations unless protected by additional means |
| IP Suitability | IP20 |
| Operating Temperature | -40°C minimum without impact; 75°C maximum continuous |
| Dielectric Strength | Withstands 2,000 V minimum |
| Current Interrupting | Certified for current interrupting at full rated current |
| Flammability | UL 94 V-0 |
| Identification | Ratings permanently marked on the device; terminals identified in accordance with UL 498 and CSA |
| Dimensions | 3.28 in. long × 1.81 in. wide |
| Weight | 0.65 lb |
| Packaging | Single pack |
