Straight Blade Receptacle, 50A, 125/250V, 14-50R, Black, Model HBL9450A
Pickup available at IES - Mississauga
Usually ready in 4 hours
Shipping & Pickup Information
In-stock items typically ship next business day.
Additional shipping charges may apply to oversized or freight items. Shipping rates calculated at checkout.
Free pickup from our local warehouses in Mississauga & Scarborough. Usually ready within 1 business day.
Returns available on eligible items.
This heavy-duty straight blade receptacle delivers safe, efficient 50A, 125/250V power for plug-in EV charging stations and other high-demand equipment. Industrial-grade construction with secure clamping terminals and 3-pole, 4-wire grounding stands up to frequent insertions and demanding job-site conditions. Back and side wiring with a straightforward termination design makes installation quick for electricians and DIY owners alike.
Specifications
| Application | EV Charging |
| Type | Receptacle |
| Colour | Black |
| Amperage Rating | 50 A |
| Voltage Rating | 125/250 V |
| Wattage | 12500 W |
| Phase | Single Phase |
| Number of Poles | 3-Pole |
| Number of Wires | 4-Wire Grounding |
| Wire Size | #12 AWG to #4 AWG |
| Connectivity | Back and Side Wired Screw Terminals |
| Maximum Horsepower | 3 |
| Operating Temperature | Maximum continuous 75°C and minimum -40°C without impact |
| Environmental Conditions | Indoor Dry Unless Protected By Additional Means |
| Flammability Rating | UL 94 V-0 |
| IP Suitability | IP20 |
| Dielectric Strength | Withstands 2,000V minimum |
| Certification | CSA/UL Listed |
| Material | Thermoplastic/Composite |
| Housing | Reinforced Thermoplastic Polyester |
| Box Terminals | Copper |
| Contacts | Brass |
| Ground Shunt | Brass |
| Mounting Plate | .062 in. (1.5) Pre-Plated Steel |
| Mounting Hardware | Screw Mounting |
| OEM Brand Name | Hubbell Wiring Device-Kellems |
| Dimensions | 3.28 in x 2.75 in x 2.44 in |
| Weight | 0.7 lb |
