STANPRO Electronic Compact Fluorescent Ballast 347V, Model E21338-347-TDE FLX
STANPRO Electronic Compact Fluorescent Ballast 347V, Model E21338-347-TDE FLX
Pickup available at Independent Electric Supply
Usually ready in 4 hours
The Stanpro E21338-347-TDE FLX is a 347V electronic program-start ballast designed for professional electricians and lighting contractors working on commercial and industrial installations across Canada. Engineered for use with PL18/TTT 18W compact fluorescent lamps, this single-lamp ballast operates on 347V line voltage — the standard for Canadian commercial distribution — making it a reliable choice for office, retail, and light-industrial fixture retrofits and new builds. Program-start technology extends lamp life by preheating the cathodes before ignition, reducing wear on the lamp and minimising flicker at startup. With a high ballast factor (>1.00) and a rated minimum start temperature of -20°C, it performs dependably in cold storage areas, parkades, and unheated service spaces. The FlexConnect design simplifies wiring and speeds up installation on the job site.
Specifications
| Model | E21338-347-TDE FLX |
| Line Voltage | 347V |
| Rated Lamp Watts | 13W |
| Input Power (ANSI) | 20W |
| Lamp Type | PL18/TTT (18W) |
| Number of Lamps | 1 |
| Ballast Start Type | Program Start (PS) |
| Ballast Factor | High (>1.00) |
| Ballast Efficacy Factor (BEF) | 7.74 |
| Minimum Start Temperature | −20°C (−4°F) |
| UPC | 69549312777 |
| Brand | Stanpro – FlexConnect |
