Male Vinyl-Insulated Disconnect 16-14 AWG, Blue, .250", 50PK
$19.74
/
In Stock
Shipping calculated at checkout.
NVENT - ILSCO
MFR #VDMT-14-250-P50
UPC #783669214376
Male Vinyl-Insulated Disconnect 16-14 AWG, Blue, .250", 50PK
$19.74
/
In Stock
Shipping calculated at checkout.
Pickup available at IES - Mississauga
Usually ready in 4 hours
Related categories
This vinyl-insulated brass male disconnect terminal with a butted compression construction provides a secure 0.250" tab connection for 16-14 AWG copper conductors, rated at 300 V and 75°C for commercial and industrial wiring applications.
- Wire Range: 16-14 AWG (solid and stranded copper)
- Tab Size: 0.250" × .032"
- Pack Quantity: 50
Specifications
| Conductor Range (CU Solid) | 14 Sol – 16 Sol |
| Conductor Range (CU Stranded) | 14 Str – 16 Str |
| Tab Size | 0.250" × .032" |
| Tongue Type | Disconnect (Male) |
| Connection Type | Compression |
| Construction | Butted |
| Conductor Material | Copper |
| Body Material | Brass |
| Connector Finish | Tin |
| Insulation | Vinyl |
| Colour Code | Blue |
| Voltage Rating | 300 V |
| Temperature Rating | 75°C |
| Number of Conductors | 1 |
| Installation Tooling | ILST-22K |
| Installing Dies | Die Set C |
| Certification | UL/cUL 310 Listed |
| Pack Quantity | 50 |
| Brand | nVent ILSCO |
