600A AC/DC Auto-Ranging TRMS Clamp Meter with Worklight, Model CL810
600A AC/DC Auto-Ranging TRMS Clamp Meter with Worklight, Model CL810
Pickup available at IES - Mississauga
Usually ready in 4 hours
The Klein Tools CL810 True RMS Digital Clamp Meter is built for professional electricians and contractors who need reliable, accurate measurements across every job — from residential panels to industrial equipment. With a measurement range spanning AC/DC voltage, AC/DC current from 10 mA to 600 A, resistance, DC micro amps, temperature, capacitance, frequency/duty cycle, and inrush current, the CL810 handles virtually every electrical task on the job site. The integrated Low Impedance (LoZ) mode eliminates ghost voltages to prevent false readings, while the built-in worklight and non-contact voltage detection in the clamp jaw keep you safe and efficient in tight, dark, or confined spaces. Rated IP40 and drop-tested to 2 m (6.6 ft), this is a meter built to take the punishment of daily trade use.
Specifications
| Measurement Functions | AC/DC Voltage, AC/DC Current, Resistance, DC Micro Amps, Temperature, Diode Test, Continuity, Capacitance, Frequency/Duty Cycle, Inrush |
| Current Measurement Range | 10 mA – 600 A AC/DC |
| Display | Transflective Reverse-Contrast LCD — excellent visibility in sunlight and low-light environments |
| Dial | Illuminated for clear visibility in low-light conditions; thumb-adjustable |
| Low Impedance (LoZ) Mode | Yes — eliminates ghost voltages for accurate readings on sensitive circuits |
| Worklight | Integrated — illuminates work area in dark or confined spaces |
| Non-Contact Voltage Detection | Integrated in clamp jaw; audible and visual indicators intensify as clamp approaches voltage source |
| Ingress Protection | IP40 |
| Drop Protection | 2 m (6.6 ft) |
| Ergonomics | Overmould grip; side-mounted test lead holder; back mount for optional magnetic hanger (Cat. Nos. 69445 or 69417) |
| Batteries | 3 × AAA (included) |
| What's Included | Clamp Meter, Right-Angle Input Test Leads, Thermocouple, Storage Pouch, Instruction Manual, 3 × AAA Batteries |
