Hubbell Industrial Grade 30 Amp 125V Twist-Lock Male Plug, Model HBL2611
Pickup available at IES - Mississauga
Usually ready in 4 hours
Shipping & Pickup Information
In-stock items typically ship next business day.
Additional shipping charges may apply to oversized or freight items. Shipping rates calculated at checkout.
Free pickup from our local warehouses in Mississauga & Scarborough. Usually ready within 1 business day.
Returns available on eligible items.
Keep commercial and industrial equipment securely connected with this industrial-grade Hubbell Twist-Lock® male plug, rated for 30A at 125 VAC. Its locking connection helps prevent accidental disconnections, while the enhanced cord grip reduces strain on wire terminations. Clear, funnel-shaped wire entries simplify wiring, and a built-in dust shield helps protect the wiring chamber during installation and use in indoor dry environments.
Specifications
| Product type | Industrial-grade grounding Insulgrip® Twist-Lock® male plug |
| Brand | Hubbell Wiring Device-Kellems |
| Current rating | 30 A |
| Voltage rating | 125 VAC, single phase |
| NEMA configuration | L5-30P |
| Poles and wires | 2-pole, 3-wire grounding |
| Maximum horsepower | 2 hp |
| Termination | Pressure terminal screws; #10-32 brass screws with Phillips, slotted and Robertson drives |
| Wire accommodation | #16 AWG to #8 AWG stranded copper wire only |
| Cord diameter range | 0.360–0.930 in |
| Mounting | Cord mounted |
| Housing and cord clamp | Nylon |
| Blades | Brass |
| Assembly screws | Nickel-plated steel |
| Terminal clamp | Nickel-plated cold-rolled steel |
| Terminal retainer | Clear polycarbonate |
| Colour | Black and white |
| Environmental conditions | Indoor dry unless protected by additional means; IP20 suitability |
| Operating temperature | Maximum continuous 75°C; minimum -40°C without impact |
| Current interrupting | Certified for current interrupting at full rated current |
| Dielectric strength | Withstands 2,000 V minimum |
| Flammability | HB or better per UL 94 / CSA 22.2 No. 0.17 |
| Terminal identification | In accordance with UL 498 |
| Dimensions (L × W × H) | 2.26 × 2.26 × 2.75 in; standard sized |
| Weight | 0.25 lb |
| UPC | 783585038735 |
